Cable ladder four cross, also known as cable ladder cross junction or ladder type cable cross fitting, is specially designed and engineered for creating four-way intersections in cable ladder systems, allowing heavy power cables and control cables to branch in four directions from a single junction point. As the reliable cable ladder manufacturer, Lanye brand custom cable ladder four cross is available in various configurations, materials, sizes and forms to suit the location and requirements of the installation. Our cable ladder four cross can be used in almost any places including power generation plants, oil refineries, industrial facilities, shipbuilding, mining operations, substations, and heavy industrial construction, etc.
A cable ladder four cross is a pre-fabricated fitting used to create a four-way junction in a cable ladder system, allowing cables to branch in four directions (straight through and perpendicular left and right) from a central intersection point. Unlike cable tray crosses which have solid or perforated bottoms, cable ladder four crosses feature open rungs and heavy-duty side rails, maintaining the same structural characteristics as straight cable ladder sections while providing branch paths in all four directions.
Cable ladder four cross is commonly fabricated using carbon steel grades Q195 or Q235, as well as stainless steel 304/316 and aluminum. In the automated pre-galvanizing process, the carbon steel plates are immersed in a “galvanizing bath” containing molten zinc for a brief period. After being withdrawn from the bath, excess zinc is stripped away, leaving a relatively thin yet effective zinc coating on the steel surface. The cable ladder four cross is then manufactured using pre-galvanized steel through standard procedures such as punching, bending, and welding, carried out by a flexible automatic production line.
Galvanized cable ladder four cross exhibits excellent qualities including high strength, a robust design, durability, and resistance to rust. The open rung design provides excellent ventilation for cable heat dissipation while offering strong support for heavy power cables, control cables, and instrumentation wiring. The four-way design allows complex cable distribution patterns without requiring multiple separate fittings. These characteristics make it an ideal choice for cable management in heavy industrial environments where large cables require robust support and heat dissipation at central distribution points. Cable ladder four cross is the reliable cable management solution to ensure the longevity and proper functioning of heavy cables in demanding applications.
| Function | Description |
|---|---|
| Four-Way Branching | Allows cables to branch in four directions from a single junction |
| Heavy Cable Support | Robust construction for large diameter power cables |
| Ventilation | Open rungs provide excellent heat dissipation at junction |
| Cable Organization | Maintains clean cable routing at central distribution points |
| Load Distribution | Evenly distributes cable weight at four-way intersections |
| Space Efficiency | Single fitting replaces multiple tee fittings |
| Feature | Cable Ladder Four Cross | Cable Tray Four Cross |
|---|---|---|
| Bottom Surface | Open rungs (spaced cross members) | Solid / Perforated bottom |
| Typical Cable Type | Heavy power (e.g., 500 MCM, 750 MCM) | Light to medium power & data |
| Load Capacity | Higher (up to 150 lb/ft or more) | Moderate (typically <100 lb/ft) |
| Airflow & Heat Dissipation | Excellent | Moderate to good |
| Small Cable Support | Poor (cables may sag) | Good to excellent |
| Typical Industries | Power gen, oil & gas, mining | Commercial, IT, light industrial |
| No | Type | Tray Width (mm) | Side Rail Height (mm) | Rung Spacing (mm) | Material | Weight (kg/pc) |
|---|---|---|---|---|---|---|
| 1 | Lanye-CLFC-1 | 200 | 50 | 225 | Pre-galvanized Steel | 18.5 |
| 2 | Lanye-CLFC-2 | 300 | 75 | 225 | Pre-galvanized Steel | 28.6 |
| 3 | Lanye-CLFC-3 | 400 | 75 | 300 | Pre-galvanized Steel | 42.8 |
| 4 | Lanye-CLFC-4 | 450 | 100 | 300 | Pre-galvanized Steel | 52.4 |
| 5 | Lanye-CLFC-5 | 500 | 100 | 300 | Hot-dip Galvanized Steel | 62.5 |
| 6 | Lanye-CLFC-6 | 600 | 100 | 300 | Hot-dip Galvanized Steel | 78.2 |
| 7 | Lanye-CLFC-7 | 600 | 150 | 300 | Hot-dip Galvanized Steel | 96.6 |
| 8 | Lanye-CLFC-8 | 700 | 150 | 300 | Hot-dip Galvanized Steel | 112.4 |
| 9 | Lanye-CLFC-9 | 800 | 150 | 300 | Stainless Steel 304 | 135.5 |
| 10 | Lanye-CLFC-10 | 900 | 150 | 300 | Stainless Steel 316 | 158.6 |
| Tray Width (mm) | Side Rail Height (mm) | Rung Spacing (mm) | Overall Size (mm) | Typical Application |
|---|---|---|---|---|
| 200-300 | 50-75 | 225 | 400-600 | Light to medium power |
| 400-500 | 75-100 | 300 | 800-1000 | Heavy power, industrial |
| 600-900 | 100-150 | 300 | 1200-1800 | Extra heavy power, mining |
| Tray Width (mm) | Side Rail Height (mm) | Rung Spacing (mm) | Overall Size (mm) | Typical Application |
|---|---|---|---|---|
| 200-300 | 50-75 | 225 | 400-600 | Light to medium power |
| 400-500 | 75-100 | 300 | 800-1000 | Heavy power, industrial |
| 600-900 | 100-150 | 300 | 1200-1800 | Extra heavy power, mining |
| Rung Type | Cross Section | Best For |
|---|---|---|
| Round Bar | 8mm-12mm diameter | General purpose, lighter loads |
| Flat Bar | 25mm x 5mm to 40mm x 6mm | Heavy loads, cable sliding |
| Accessory | Availability |
|---|---|
| Divider / Separator Kit | Yes |
| Splice Plates and Hardware | Yes |
| Support Brackets | Yes |
| Cover (where required) | Yes |
| Earth Bonding Kits | Yes |
| Seismic Rated Brackets | Yes |
Lanye custom cable ladder four cross has the following advantages which make it an excellent choice for efficient cable management solutions.
The four cross fitting allows heavy power and control cables to be distributed in four directions from a single junction point. This is essential for complex cable routing in large industrial facilities where cable paths must radiate to multiple zones, equipment clusters, or distribution panels from central points.
The open rung design of cable ladder four crosses allows hot air to rise away from cables, preventing heat buildup that can degrade insulation and reduce cable lifespan. This is particularly important at four-way junctions where multiple cable paths converge and heat accumulation could be significant.
Cable ladder four crosses are designed for heavy-duty applications. With side rail heights up to 150mm and rung spacing optimized for strength, Lanye cable ladder four crosses can support heavy power cables including 500 MCM, 750 MCM, and larger, with safe working loads up to 150 lb/ft or more at the junction.
Cable ladder four crosses come in various sizes and materials, allowing customization to suit specific installation needs. Equal crosses have the same width on all four legs, while reducing four crosses can have different widths for main and branch runs.
All rungs and rail edges are deburred and rounded to prevent cable jacket abrasion during pulling through the four-way junction. Flat bar rungs are recommended for cable sliding applications as they provide a smoother surface than round rungs.
The zinc coating (or stainless steel/aluminum material) provides excellent corrosion resistance, safeguarding the four cross from rust and corrosion due to moisture, chemicals, and environmental factors. HDG and stainless steel options provide maximum protection for outdoor and harsh environments.
Each of the four legs includes pre-punched splice holes that align perfectly with straight cable ladder sections. Splice plates, bolts, and grounding jumpers are included with every four cross order.
The four cross is designed with gradual transitions and radiused corners to allow heavy cables to flow smoothly through the intersection without sharp edges that could damage insulation or impede pulling.
A single cable ladder four cross can replace multiple tee fittings and additional straight sections, simplifying installation, reducing material costs, and minimizing the number of field connections required.
Custom cable ladder four crosses offer OEM/ODM options for tailored solutions to meet specific project requirements, including custom widths, reducing configurations, special rung spacing, and unique materials.
Cable ladder four cross is widely used across many industries including power generation, oil and gas, industrial manufacturing, mining, shipbuilding, and heavy infrastructure where complex cable distribution from central points is required.
In power plants, cable ladder four crosses are used at main cable distribution points where power cables branch to multiple generators, transformers, switchgear, and auxiliary equipment from central cable trenches or trays.
Refineries require complex cable distribution from central control rooms and power centers to process units, storage tanks, and loading facilities. Cable ladder four crosses provide organized four-way distribution in these demanding environments.
Large industrial facilities use cable ladder four crosses at main electrical rooms and distribution hubs where power and control cables branch to multiple production lines, large machinery, and process equipment arranged in grid patterns.
Mines and processing plants have extensive cable distribution networks. Cable ladder four crosses provide branch routing from main power feeds to crushers, conveyors, pumps, and processing equipment located in multiple directions.
Large vessels including cargo ships, cruise ships, and naval vessels use cable ladder four crosses at main electrical distribution points where power branches to propulsion, navigation, lighting, and shipboard systems in multiple compartments.
Substations require complex cable routing from transformers to switchgear, control rooms, and outgoing feeders. Cable ladder four crosses provide organized four-way cable distribution in outdoor and indoor substation environments.
For large data centers, the main utility feeder distribution from transformers to UPS systems and from UPS to PDU panels often requires heavy cable ladder systems with four crosses at central distribution points.
Large treatment facilities use cable ladder four crosses to distribute power and control cables from main electrical rooms to pumps, blowers, and processing equipment located in multiple directions across the facility.
Determine the optimal location for the four cross fitting. Consider cable entry/exit directions, future expansion needs, and support requirements. Central distribution points should be located for efficient cable routing to all four directions.
Ensure the four cross is oriented correctly for your cable routing (straight through plus left and right branches). Mark the intended cable paths before installation.
Due to the weight concentration at four-way junctions, install supports within 12 inches on each side of all four legs. For large four crosses (width over 600mm), additional support under the junction is recommended. Use heavy-duty seismic-rated brackets where required.
Connect straight ladder sections to each of the four legs using splice plates and hardware. Do not fully tighten until all sections are aligned.
If cable separation is required (power vs. data, different voltages), install divider-compatible inserts that maintain separation through all four legs of the four cross.
Route cables through the four cross, respecting minimum bend radii. For large power cables, pull cables in sequence to avoid overloading the junction. For heavy cable bundles, use cable rollers at the junction.
Secure cables with cable ties or heavy-duty cable cleats. For heavy cables under fault conditions, use appropriate cable cleats to prevent dangerous movement.
For metal ladder systems, ensure electrical continuity across the four cross using bonding jumpers across all four legs as required by NEC and local codes.
| Method | Advantages | Disadvantages |
|---|---|---|
| Four Cross (single fitting) | One fitting, clean installation, certified load rating, fewer connections | Higher cost per fitting, requires precise planning |
| Four Tee Fittings | Lower individual fitting cost | Requires four fittings and additional straight sections, many connections |
| Field-Fabricated | Can be adapted on site | Labor intensive, quality varies, no load certification |
Lanye cable ladder four crosses are built for heavy industrial applications with robust side rails, securely welded rungs, and certified load ratings for four-way junctions.
All Lanye cable ladder four crosses are precision-manufactured to match straight ladder sections exactly, ensuring proper fit and alignment on all four legs.
As a professional cable ladder manufacturer, Lanye can provide custom four crosses based on project drawings, load requirements, and specific branch configurations including reducing four crosses.
Lanye supports OEM and ODM supply for distributors, contractors, and engineering buyers. Private labeling and custom configurations are available.
All Lanye cable ladder four crosses undergo strict quality control including dimensional inspection, weld inspection, load testing verification, and finish inspection.
A: A cable ladder four cross is a four-way junction fitting used in cable ladder systems, allowing heavy power and control cables to branch in four directions (straight through, left, and right) from a single junction point.
A: A cable ladder tee provides three-way branching (straight through plus one side branch). A cable ladder four cross provides four-way branching (straight through plus left and right branches), allowing cable distribution to two sides from a single junction.
A: Cable ladder four crosses are designed for heavy power cables. For small diameter cables (e.g., instrumentation, data), Lanye recommends using cable tray four crosses with solid or perforated bottoms to prevent cable sagging between rungs.
A: An equal four cross has the same width on all four legs. A reducing four cross has branches that may be different widths from the main run. Lanye offers both types for applications where cable volume varies by direction.
A: Due to the concentrated load at four-way junctions, Lanye recommends supports within 12 inches on each side of all four legs. For four crosses wider than 600mm or heavy loads, additional support under the junction is recommended.
A: Yes. Lanye offers divider-compatible cable ladder four crosses with pre-slotted side rails that maintain continuous separation through all four legs of the junction. This is essential for separating power and data cables or different voltage levels.
A: Lanye cable ladder four crosses are available in pre-galvanized steel, hot-dip galvanized steel (HDG), stainless steel 304, stainless steel 316, and aluminum. For outdoor and corrosive environments, HDG or stainless steel is recommended.
A: Standard sizes and materials from Lanye typically ship in 5-7 business days. Custom sizes, reducing four crosses, or special materials require 10-15 business days.
A: Load capacity depends on width, side rail height, material, and rung spacing. Example: 600mm wide, 100mm side rail, HDG steel: safe working load of approximately 100-120 lb/ft for the four cross section. Always refer to Lanye certified load tables for specific configurations.
A: Yes. Lanye cable ladder four crosses meet NEMA VE 1, IEC 61537, and CSA C22.2 No. 126.1 standards. CE and ISO 9001 certified.
A: Yes. Lanye offers sample cable ladder four crosses for customer evaluation. Please contact our sales team to discuss sample requirements, size, material, and lead time.
A: Use a laser level or string line to establish reference lines for both axes. Install supports first, then place the four cross, then connect straight sections. Do not fully tighten any connections until all four legs are aligned. For complex installations, pre-assemble on the floor.
